EN/IEC 60947-4-1 || UL 60947-4-1A || CSA C22.2 No 60947-4-1
Connections - Terminals:
control circuit push-in termination 1 0.2-2.5 mm² solid stranded without cable end sleeve AWG 26...AWG 12 || control circuit push-in termination 1 0.25-2.5 mm² flexible with cable end sleeve AWG 24...AWG 14 || control circuit push-in termination 2
Environmental Disclosure:
ENVPEP2105013
Electromagnetic Compatibility:
EMC immunity conforming to IEC 60947-4-1 || emission tests criteria A conforming to IEC 60947-4-1 || immunity to radiated radio-electrical interference - test level: 20 V/m conforming to EN/IEC 61000-4-3 || voltage dips and interruptions immunity tes
Hold-In Power Consumption In Va:
13-13 VA
Sustainable Offer Status:
Green Premium product
Rohs Exemption Information:
Yes
Poles Description:
3P
Mercury Free:
Yes
Eu Rohs Directive:
Compliant with Exemptions
Ambient Air Temperature For Operation:
-25-60°C
Pollution Degree:
3 IEC 60947-1
Ambient Air Temperature For Storage:
-60-80°C
Operating Time:
20...35 ms opening || 40...55 ms closing
Hold-In Power Consumption In W:
8-8 W
Permissible Ambient Air Temperature Around The Device:
-40-70°C at Uc
Mechanical Durability:
5 Mcycles
Range:
TeSys
Depth:
94.0 mm
Country of Origin:
China
California Proposition 65:
WARNING: This product can expose you to chemicals including: Styrene, which is known to the State of California to cause cancer, and Bisphenol A (BPA), which is known to the State of California to cause birth defects or other reproductive harm. For m
Circularity Profile:
ENVEOLI2105013
Maximum Operating Rate:
600 cyc/mn 60°C
Inrush Power In Va:
295-295 VA
Coil Technology:
built-in bidirectional peak limiting
Operating Altitude:
9842.52 ft (3000 m) without derating || 5000 m with derating factor
