Schneider Electric NSYCCOTH120VID Electronical Thermostat 110-120V

(No reviews yet) Write a Review

Write a Review

Schneider Electric NSYCCOTH120VID Electronical Thermostat 110-120V

Rating Required Select Rating 1 star (worst) 2 stars 3 stars (average) 4 stars 5 stars (best)

Name

Email Required

Review Subject Required

Comments Required

SKU:

NSYCCOTH120VID

UPC:

3606480152610

MPN:

Condition:

New

Product Name:

ClimaSys CC

Mercury Free:

Yes

Circularity Profile:

N/A

Information Displayed:

temperature in °F || temperature in °C

Weee:

The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.

Number Of Outputs:

2 ventilation/heating function

Color:

Light gray

Flame Retardance:

self-extinguishing conforming to UL94 (material V0)

Hysteresis:

2 K programmed value

Reach Regulation:

Reference contains Substances of Very High Concern above the threshold

Mounting Location:

Spacial upright || 35 mm DIN rail || cross rails || on mounting plate

Input Voltage:

90...140 V AC

Eu Rohs Directive:

Compliant with Exemptions

China Rohs Regulation:

Product out of China RoHS scope. Substance declaration for your information.

Mounting Mode:

by screws || clipped

Warranty:

18 months

Material:

PC

Rohs Exemption Information:

Yes

Sensor Type:

optional NTC external sensor

Height:

external 85 mm

Range:

ClimaSys

Sustainable Offer Status:

Green Premium product

Display Type:

OLED screen

Ambient Air Temperature For Operation:

-40-80 °C

Maximum Switching Capacity:

4 A 120 V AC

Electrical Connection:

10 terminals 2.5 mm²

Depth:

external 44 mm

Width:

external 56 mm

Product Certifications:

UR

Temperature Setting Range:

-40-80 °C

Product Or Component Type:

electronical thermostat

Environmental Disclosure:

ENVPEP2103012EN

Catalog:

View

Datasheet:

View
