Schneider Electric NSYCRN33200T Crn 300X300X200 Glazed Door

(No reviews yet) Write a Review
SKU:
NSYCRN33200T
UPC:
3606480212505
Condition:
New
Removable Parts:
door by hinges || cable gland plate by screws
Range:
Spacial
Product Name:
Spacial CRN
Variant Particularity:
sides made from a single folded section || back welded with double profile forming a protected sealed area
Lock Type:
3 mm double-bar lock
Mercury Free:
Yes
Color:
Gray RAL 7035)
Number Of Doors:
front face 1
Enclosure Nominal Height:
300 mm
Device Application:
multi-purpose
Sustainable Offer Status:
Green Premium product
Door Opening Side:
reversible 120 °)
Material:
body steel || door steel and security glass
Standards:
IEC 62208
Ip Degree Of Protection:
IP66 IEC 60529
Device Composition:
1 body || 1 cable gland plate || 1 door || 1 lock
Environmental Disclosure:
ENVPEP100104EN
Door Type:
Glass
Net Weight:
5.019 kg
Enclosure Nominal Depth:
200 mm
Enclosure Nominal Width:
300 mm
Circularity Profile:
N/A
Surface Finish:
epoxy-polyester powder
Accessibility For Operation:
front
China Rohs Regulation:
Product out of China RoHS scope. Substance declaration for your information.
Installation Accessory Type:
wall-mounting
Warranty:
18 months
Product Or Component Type:
compact enclosure
Eu Rohs Directive:
Pro-active compliance (Product out of EU RoHS legal scope)
Reach Regulation:
Reference contains Substances of Very High Concern above the threshold
Ik Degree Of Protection:
IK08 IEC 62262
Type Of Gland Plate:
standard
Product Certifications:
UL || cUL || DNV-GL
Rohs Exemption Information:
Yes
Mounting Plate Description:
without mounting plate
Brochure:
View
Datasheet:
View
$247.68

Description

The Spacial CRN wall-mounting compact enclosure comes in grey colour and designed for multi-purpose application. This compact enclosure is composed of body, cable gland plate, door, lock. The compact enclosure is made of steel (body), steel and security glass (door), making it durable and resistant. It has IP66 and IK08 protection level, which can help protect against impact, water and dust. The dimensions are (W) 300 mm x (H) 300 mm x (D) 200 mm. It features a back welded with double profile forming a protected sealed area, sides made from a single folded section. The door type is glazed, it has 1 door(s) and the door opening side is reversible. Equipped with a 3 mm double-bar lock lock type. Featuring a epoxy-polyester powder surface finish, which ensures a bright, even and inviting finish. This device is qualified as a green premium product, with minimal use of hazardous substances. This compact enclosure is c.UL certified.
