Schneider Electric NSYCRN34200 Crn 300X400X200 One Plain Door
Schneider Electric
$116.75
(No reviews yet)
Write a Review
Write a Review
Schneider Electric
Schneider Electric NSYCRN34200 Crn 300X400X200 One Plain Door
The Spacial CRN wall-mounting compact enclosure comes in grey colour and designed for multi-purpose application. This compact enclosure is composed of body, cable gland plate, door, lock. The compact enclosure is made of steel (body), making it durable and resistant. It has IP66 and IK10 protection level, which can help protect against impact, water and dust. The dimensions are (W) 400 mm x (H) 300 mm x (D) 200 mm. It features a back welded with double profile forming a protected sealed area, sides made from a single folded section. The door type is plain, it has 1 door(s) and the door opening side is reversible. Equipped with a 3 mm double-bar lock lock type. Featuring a epoxy-polyester powder surface finish, which ensures a bright, even and inviting finish. This device is qualified as a green premium product, with minimal use of hazardous substances. This compact enclosure is c.UL certified.
- Enclosure Nominal Height:
- 300 mm
- Ik Degree Of Protection:
- IK10 IEC 62262
- Door Type:
- Solid
- Product Or Component Type:
- compact enclosure
- Installation Accessory Type:
- wall-mounting
- Sustainable Offer Status:
- Green Premium product
- Eu Rohs Directive:
- Pro-active compliance (Product out of EU RoHS legal scope)
- Rohs Exemption Information:
- Yes
- Product Name:
- Spacial CRN
- Range:
- Spacial
- Removable Parts:
- door by hinges || cable gland plate by screws
- Ip Degree Of Protection:
- IP66 IEC 60529
- Circularity Profile:
- N/A
- Device Composition:
- 1 body || 1 cable gland plate || 1 door || 1 lock
- Number Of Doors:
- front face 1
- Variant Particularity:
- sides made from a single folded section || back welded with double profile forming a protected sealed area
- Material:
- body steel
- Reach Regulation:
- Reference contains Substances of Very High Concern above the threshold
- Type Of Gland Plate:
- standard
- Mercury Free:
- Yes
- Product Certifications:
- cUL || UL || DNV-GL
- Warranty:
- 18 months
- Net Weight:
- 5.94 kg
- Device Application:
- multi-purpose
- Enclosure Nominal Depth:
- 200 mm
- Surface Finish:
- epoxy-polyester powder
- Environmental Disclosure:
- ENVPEP100104EN
- Mounting Plate Description:
- without mounting plate
- Door Opening Side:
- reversible 120 °)
- Accessibility For Operation:
- front
- China Rohs Regulation:
- Product out of China RoHS scope. Substance declaration for your information.
- Standards:
- IEC 62208
- Color:
- Gray RAL 7035)
- Enclosure Nominal Width:
- 400 mm
- Lock Type:
- 3 mm double-bar lock
