Schneider Electric NSYCRN86200 Crn 800X600X200 One Plain Door

(No reviews yet) Write a Review
SKU:
NSYCRN86200
UPC:
3606480211850
Condition:
New
Lock Type:
3 mm double-bar lock
Eu Rohs Directive:
Pro-active compliance (Product out of EU RoHS legal scope)
Product Certifications:
cUL || UL || DNV-GL
China Rohs Regulation:
Product out of China RoHS scope. Substance declaration for your information.
Material:
body steel
Surface Finish:
epoxy-polyester powder
Warranty:
18 months
Rohs Exemption Information:
Yes
Range:
Spacial
Mounting Plate Description:
without mounting plate
Product Or Component Type:
compact enclosure
Standards:
IEC 62208
Accessibility For Operation:
front
Device Application:
multi-purpose
Net Weight:
18.138 kg
Enclosure Nominal Height:
800 mm
Circularity Profile:
N/A
Number Of Doors:
front face 1
Environmental Disclosure:
ENVPEP100104EN
Reach Regulation:
Reference contains Substances of Very High Concern above the threshold
Enclosure Nominal Width:
600 mm
Product Name:
Spacial CRN
Installation Accessory Type:
wall-mounting
Door Type:
Solid
Removable Parts:
door by hinges || cable gland plate by screws
Ik Degree Of Protection:
IK10 IEC 62262
Enclosure Nominal Depth:
200 mm
Device Composition:
1 body || 1 cable gland plate || 1 door || 1 lock
Type Of Gland Plate:
standard
Sustainable Offer Status:
Green Premium product
Door Opening Side:
reversible 120 °)
Ip Degree Of Protection:
IP66 IEC 60529
Mercury Free:
Yes
Color:
Gray RAL 7035)
Variant Particularity:
back welded with double profile forming a protected sealed area || sides made from a single folded section
Brochure:
View
Catalog:
View
Datasheet:
View
$227.88

Description

The Spacial CRN wall-mounting compact enclosure comes in grey colour and designed for multi-purpose application. This compact enclosure is composed of body, cable gland plate, door, lock. The compact enclosure is made of steel (body), making it durable and resistant. It has IP66 and IK10 protection level, which can help protect against impact, water and dust. The dimensions are (W) 600 mm x (H) 800 mm x (D) 200 mm. It features a back welded with double profile forming a protected sealed area, sides made from a single folded section. The door type is plain, it has 1 door(s) and the door opening side is reversible. Equipped with a 3 mm double-bar lock lock type. Featuring a epoxy-polyester powder surface finish, which ensures a bright, even and inviting finish. This device is qualified as a green premium product, with minimal use of hazardous substances. This compact enclosure is c.UL certified.
