Schneider Electric

Schneider Electric NSYDCD2412 Cable Entry System 24X12

SKU:

NSYDCD2412

UPC:

3606489429027

MPN:

Condition:

New

Resistance To Chemical Agents:

good resistant to alcohols || good resistance to mineral oils and greases || good resistance to weak acids and bases || good resistance to fuels

Rohs Exemption Information:

Yes

Product Or Component Type:

cable entry

Sustainable Offer Status:

Green Premium product

Accessory / Separate Part Category:

cable management accessory

Eu Rohs Directive:

Pro-active compliance (Product out of EU RoHS legal scope)

Flame Retardance:

V0 conforming to UL 94

Width:

58 mm

Quantity Per Set:

set of 1

Mounting Location:

enclosure bottom

Ip Degree Of Protection:

IP65 IEC 60529

Device Application:

multi-purpose

Cable Entry:

12 grommets 2-12 mm

Ambient Air Temperature For Operation:

-30-100 °C

Environmental Disclosure:

ENVPEP100104EN

Reach Regulation:

Reference contains Substances of Very High Concern above the threshold

Lead Time:

Usually Ships within 4 Weeks

Circularity Profile:

N/A

Material:

polypropylene

China Rohs Regulation:

Product out of China RoHS scope. Substance declaration for your information.

Height:

148 mm

Cut-Out Dimensions:

112 x 36 mm

Mercury Free:

Yes

Depth:

18 mm

Net Weight:

0.205 kg

Range:

Spacial

Catalog:

View

Datasheet:

View
