Schneider Electric NSYFXT6060 Fixed Shelf 30X482X490, 600X600
Schneider Electric
$212.01
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
Spacial SM fixed tray for enclosure of W is 600 x D is 600 mm. Tray dimensions are H is 30 x W is 482 x D is 490 mm. Maximum Load 150 kg.
- Enclosure Nominal Dimensions:
- W: 600 mm D: 600 mm
- Quantity Per Set:
- set of 1
- China Rohs Regulation:
- Product out of China RoHS scope. Substance declaration for your information.
- Sustainable Offer Status:
- Green Premium product
- Maximum Load:
- 150 kg evenly distributed
- Height:
- 30 mm
- Mercury Free:
- Yes
- Product Or Component Type:
- fixed tray
- Device Composition:
- 1 fixed tray || fixing elements
- Material:
- steel
- Reach Regulation:
- Reference contains Substances of Very High Concern above the threshold
- Range Compatibility:
- Spacial Spacial SF || Spacial Spacial SM
- Color:
- Gray RAL 7035)
- Warranty:
- 18 months
- Depth:
- 490 mm
- Circularity Profile:
- N/A
- Range:
- Spacial
- Width:
- 482 mm
- Adjustment:
- adjustable in depth every 25 mm
- Accessory / Separate Part Category:
- installation accessory
- Rohs Exemption Information:
- Yes
- Device Application:
- multi-purpose || PC application
- Surface Finish:
- epoxy-polyester powder
- Eu Rohs Directive:
- Pro-active compliance (Product out of EU RoHS legal scope)
- Environmental Disclosure:
- ENVPEP110923EN
- Mounting Support:
- direct to the structure || 40 mm cross rails
- Catalog:
- View
- Datasheet:
- View
