Schneider Electric NSYPLA2074G 7035 Fs Pol 2000X750X420 Ip65

Schneider Electric NSYPLA2074G 7035 Fs Pol 2000X750X420 Ip65

Schneider Electric
SKU:
NSYPLA2074G
|
UPC:
3.61E+12
$1,419.65
(No reviews yet) Write a Review
Condition:
New
Current Stock:
Description
Thalassa PLA Floor standing polyester enclosure completely sealed, version PLA. 2000 x 750 x 420 mm. Sealed top and bottom part assembled with side parts. 4 points door locking system with 5-mm double-bar locks. 2 doors type transparent front. Polyester reinforced with fibreglass body. Protection IP 65, IK10, Grey RAL 7035.
Additional Information
Enclosure Nominal Depth:
420 mm
Product Name:
Thalassa PLA
Standards:
UL 508 A || IEC 62208
Range:
Thalassa
Body Type:
sealed top and bottom part assembled with side parts
Device Application:
multi-purpose
Nema Degree Of Protection:
NEMA 12 || NEMA 3X || NEMA 2 || NEMA 5 || NEMA 13 || NEMA 3R || NEMA 3 || NEMA 3S || NEMA 1
Lock Type:
4 points lock, 5 mm double-bar
China Rohs Regulation:
Product out of China RoHS scope. Substance declaration for your information.
Product Certifications:
DNV Marine || Veritas || UL/cUL listed
Enclosure Nominal Height:
2000 mm
Sustainable Offer Status:
Green Premium product
Device Composition:
1 top part || 1 bottom part || 2 side part || 1 rear panel || 2 door
Fire Resistance:
960 °C IEC 62208
Circularity Profile:
N/A
Ambient Air Temperature For Storage:
-35-90 °C
Ik Degree Of Protection:
IK10 IEC 62262 plain door)
Electrical Insulation Class:
class II
Removable Parts:
door by hinges || rear panel by fixing element
Product Or Component Type:
suitable enclosure
Device Short Name:
PLA
Door Type:
Solid front
Color:
Gray RAL 7035)
Mercury Free:
Yes
Ip Degree Of Protection:
IP65 IEC 60529 completely sealed)
Door Opening Side:
reversible 120 °)
Material:
polyester reinforced with fibreglass
Rohs Exemption Information:
Yes
Environmental Disclosure:
ENVPEP110505EN
Number Of Doors:
2
Enclosure Nominal Width:
750 mm
Accessibility For Operation:
rear || front
Eu Rohs Directive:
Pro-active compliance (Product out of EU RoHS legal scope)
Enclosure Mounting:
floor-standing
Reach Regulation:
Reference contains Substances of Very High Concern above the threshold
Datasheet:
View
