Schneider Electric

Schneider Electric NSYPLA554TG 7035 Fs Pol 500X500X420 Glazed

SKU:

NSYPLA554TG

UPC:

3606480774942

MPN:

Condition:

New

Ik Degree Of Protection:

IK08 IEC 62262 glazed door)

Material:

polyester reinforced with fibreglass

Enclosure Nominal Depth:

420 mm

Environmental Disclosure:

ENVPEP110505EN

Range:

Thalassa

Mercury Free:

Yes

Product Or Component Type:

suitable enclosure

Ambient Air Temperature For Storage:

-35-90 °C

Removable Parts:

door by hinges || rear panel by fixing element

China Rohs Regulation:

Product out of China RoHS scope. Substance declaration for your information.

Device Application:

multi-purpose

Electrical Insulation Class:

class II

Lock Type:

2 points lock, 5 mm double-bar

Circularity Profile:

N/A

Product Certifications:

Veritas || DNV Marine || UL/cUL listed

Rohs Exemption Information:

Yes

Eu Rohs Directive:

Pro-active compliance (Product out of EU RoHS legal scope)

Device Short Name:

PLA

Nema Degree Of Protection:

NEMA 3X || NEMA 12 || NEMA 3S || NEMA 1 || NEMA 2 || NEMA 13 || NEMA 5 || NEMA 3R || NEMA 3

Accessibility For Operation:

rear || front

Device Composition:

1 top part || 1 bottom part || 2 side part || 1 rear panel || 1 door

Enclosure Mounting:

floor-standing

Standards:

UL 508 A || IEC 62208

Sustainable Offer Status:

Green Premium product

Fire Resistance:

960 °C IEC 62208

Ip Degree Of Protection:

IP65 IEC 60529 completely sealed)

Door Type:

transparent front

Color:

Gray RAL 7035)

Product Name:

Thalassa PLA

Enclosure Nominal Width:

500 mm

Enclosure Nominal Height:

500 mm

Door Opening Side:

reversible 120 °)

Reach Regulation:

Reference contains Substances of Very High Concern above the threshold

Number Of Doors:

1

Body Type:

sealed top and bottom part assembled with side parts

Catalog:

View

Datasheet:

View
