Schneider Electric NSYPLAZ10123G 7035 Fs Pol Plinth 1000X1250X320

(No reviews yet) Write a Review

Write a Review

Schneider Electric

Schneider Electric NSYPLAZ10123G 7035 Fs Pol Plinth 1000X1250X320

Rating Required Select Rating 1 star (worst) 2 stars 3 stars (average) 4 stars 5 stars (best)

Name

Email Required

Review Subject Required

Comments Required

SKU:

NSYPLAZ10123G

UPC:

3606480775574

MPN:

Condition:

New

Enclosure Mounting:

floor-standing

Product Certifications:

Veritas

Number Of Doors:

2

Material:

polyester reinforced with fibreglass

Door Type:

Solid front

Sustainable Offer Status:

Green Premium product

Door Opening Side:

right and left 120 °)

Accessibility For Operation:

front || bottom || rear

Environmental Disclosure:

ENVPEP110505EN

Ip Degree Of Protection:

IP54 IEC 60529 plinth type open bottom)

Body Type:

sealed top and open bottom part assembled with side parts

Device Composition:

1 top part || 1 bottom part || 2 side part || 2 door || 2 rear panel || 1 plinth

Removable Parts:

door by hinges || rear panel by fixing element

Standards:

IEC 62208

Device Application:

multi-purpose

Range:

Thalassa

China Rohs Regulation:

Product out of China RoHS scope. Substance declaration for your information.

Circularity Profile:

N/A

Lock Type:

4 points lock, handle with 5 mm double bar insert

Rohs Exemption Information:

Yes

Eu Rohs Directive:

Pro-active compliance (Product out of EU RoHS legal scope)

Color:

Gray RAL 7035)

Ambient Air Temperature For Storage:

-35-90 °C

Fire Resistance:

960 °C IEC 62208

Product Or Component Type:

suitable enclosure

Reach Regulation:

Reference contains Substances of Very High Concern above the threshold

Mercury Free:

Yes

Enclosure Nominal Width:

1250 mm

Electrical Insulation Class:

class II

Device Short Name:

PLAZ

Ik Degree Of Protection:

IK10 IEC 62262 plain door)

Enclosure Nominal Depth:

320 mm

Enclosure Nominal Height:

1000 mm

Product Name:

Thalassa PLA
