Schneider Electric NSYPLAZT776G Pol.E.Plinth+Can750X750X620Mm Ip44

(No reviews yet) Write a Review

Write a Review

Schneider Electric NSYPLAZT776G Pol.E.Plinth+Can750X750X620Mm Ip44

Rating Required Select Rating 1 star (worst) 2 stars 3 stars (average) 4 stars 5 stars (best)

Name

Email Required

Review Subject Required

Comments Required

SKU:

NSYPLAZT776G

UPC:

3.60648E+12

MPN:

Condition:

New

Accessibility For Operation:

bottom || rear || top || front

China Rohs Regulation:

Product out of China RoHS scope. Substance declaration for your information.

Rohs Exemption Information:

Yes

Enclosure Nominal Height:

750 mm

Enclosure Mounting:

floor-standing

Number Of Doors:

1

Material:

polyester reinforced with fibreglass

Color:

Gray RAL 7035)

Ip Degree Of Protection:

IP44 IEC 60529 with plinth type open bottom part and ventilated canopy)

Lock Type:

2 points handle lock, 5 mm double-bar

Sustainable Offer Status:

Green Premium product

Enclosure Nominal Depth:

620 mm

Device Composition:

1 top part || 1 bottom part || 2 side part || 1 rear panel || 1 door || 1 canopy || 1 plinth

Environmental Disclosure:

ENVPEP110505EN

Electrical Insulation Class:

class II

Removable Parts:

door by hinges || rear panel by fixing element || canopy by fixing element

Standards:

IEC 62208

Fire Resistance:

960 °C IEC 62208

Body Type:

open top and bottom part assembled with side parts

Door Opening Side:

reversible 180 °)

Device Application:

multi-purpose

Product Or Component Type:

suitable enclosure

Ik Degree Of Protection:

IK10 IEC 62262 plain door)

Door Type:

Solid front

Device Short Name:

PLAZT

Enclosure Nominal Width:

750 mm

Reach Regulation:

Reference contains Substances of Very High Concern above the threshold

Circularity Profile:

N/A

Mercury Free:

Yes

Product Name:

Thalassa PLA

Product Certifications:

Veritas

Range:

Thalassa

Ambient Air Temperature For Storage:

-35-90 °C

Eu Rohs Directive:

Pro-active compliance (Product out of EU RoHS legal scope)
