Schneider Electric NSYPLS1827G 7035 Transp Pls Box18X27X18
Schneider Electric
$52.56
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
Thalassa PLS box polyester rear with transparent PC cover. 180 x 270 x 180 mm. Insulating modular box. One piece moulded body. Wall mounted. High transparent cover, cover locking screw removable. Polyester reinforced with fibreglass rear, polycarbonate cover. Grey RAL 7035. IP65, IK09, NEMA (13,4X) 960°C fire resistance. Insulation Class II.
- Ambient Air Temperature For Storage:
- -30-70 °C
- Circularity Profile:
- N/A
- Eu Rohs Directive:
- Pro-active compliance (Product out of EU RoHS legal scope)
- Material:
- Cover polycarbonate || rear polyester reinforced with fibreglass
- Color:
- body Gray RAL 7035)
- Enclosure Nominal Depth:
- 180 mm
- Type Of Front Cover:
- low transparent cover
- Product Name:
- Thalassa PLS
- Reach Regulation:
- Reference contains Substances of Very High Concern above the threshold
- Removable Parts:
- cover locking screw
- Standards:
- NEMA classification 13 || IEC 62208 || NEMA 4X
- Device Application:
- multi-purpose
- Device Short Name:
- PLS
- Range:
- Thalassa
- Product Or Component Type:
- insulating modular box
- Ik Degree Of Protection:
- IK09 IEC 62262
- Mercury Free:
- Yes
- Body Type:
- one piece moulded
- Sustainable Offer Status:
- Green Premium product
- Enclosure Nominal Height:
- 180 mm
- Device Composition:
- 1 cover on enclosure || 1 rear part on enclosure || locking screws
- Electrical Insulation Class:
- class II
- Enclosure Mounting:
- wall mounted
- Lock Type:
- slot screw
- Ip Degree Of Protection:
- IP66 IEC 60529
- Environmental Disclosure:
- ENVPEP110704EN
- Enclosure Nominal Width:
- 270 mm
- China Rohs Regulation:
- Product out of China RoHS scope. Substance declaration for your information.
- Rohs Exemption Information:
- Yes
- Fire Resistance:
- 960 °C IEC 62208
- Product Certifications:
- UL
- Datasheet:
- View
