Schneider Electric NSYPLS3636G 7035 Transp Pls Box36X36X18
Schneider Electric
$86.74
(No reviews yet)
Write a Review
Write a Review
Schneider Electric
Schneider Electric NSYPLS3636G 7035 Transp Pls Box36X36X18
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
Thalassa PLS box polyester rear with transparent PC cover. 360 x 360 x 180 mm. Insulating modular box. One piece moulded body. Wall mounted. High transparent cover, cover locking screw removable. Polyester reinforced with fibreglass rear, polycarbonate cover. Grey RAL 7035. IP65, IK09, NEMA (13,4X) 960°C fire resistance. Insulation Class II.
- Standards:
- NEMA classification 13 || NEMA 4X || IEC 62208
- Product Certifications:
- UL
- Enclosure Nominal Width:
- 360 mm
- Device Composition:
- 1 cover on enclosure || 1 rear part on enclosure || locking screws
- Removable Parts:
- cover locking screw
- Circularity Profile:
- N/A
- Lock Type:
- slot screw
- China Rohs Regulation:
- Product out of China RoHS scope. Substance declaration for your information.
- Environmental Disclosure:
- ENVPEP110704EN
- Device Application:
- multi-purpose
- Material:
- Cover polycarbonate || rear polyester reinforced with fibreglass
- Ip Degree Of Protection:
- IP66 IEC 60529
- Rohs Exemption Information:
- Yes
- Color:
- body Gray RAL 7035)
- Ik Degree Of Protection:
- IK09 IEC 62262
- Product Name:
- Thalassa PLS
- Product Or Component Type:
- insulating modular box
- Range:
- Thalassa
- Reach Regulation:
- Reference contains Substances of Very High Concern above the threshold
- Fire Resistance:
- 960 °C IEC 62208
- Body Type:
- one piece moulded
- Enclosure Nominal Depth:
- 180 mm
- Enclosure Nominal Height:
- 360 mm
- Device Short Name:
- PLS
- Ambient Air Temperature For Storage:
- -30-70 °C
- Electrical Insulation Class:
- class II
- Sustainable Offer Status:
- Green Premium product
- Eu Rohs Directive:
- Pro-active compliance (Product out of EU RoHS legal scope)
- Type Of Front Cover:
- low transparent cover
- Mercury Free:
- Yes
- Enclosure Mounting:
- wall mounted
- Catalog:
- View
- Datasheet:
- View
