Schneider Electric NSYPMA2754G 7035 Insul. Pol Plate F 27X54 Pls

Schneider Electric NSYPMA2754G 7035 Insul. Pol Plate F 27X54 Pls

Schneider Electric
SKU:
NSYPMA2754G
|
UPC:
3606485405360
Availability:
Contact us to confirm availability and lead times.
$15.04
Condition:
New
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
Current Stock:
Description
Thalassa PLS insulating bakelite mounting plate. For boxes H 270 x W 540 mm. Multi-purpose application. Mounting location on back inserts (fixing by screw type M6). Insulating mounting plate. 150 Kg permanent permissible load. Bakelite. Black RAL 9005.
Additional Information
Range:
Thalassa
Device Application:
multi-purpose
Mounting Plate Description:
insulating
Reach Regulation:
Free of Substances of Very High Concern above the threshold
Range Compatibility:
Thalassa Thalassa PLS
Mounting Location:
back inserts
Device Composition:
1 mounting plate
Color:
Gray RAL 7035)
Eu Rohs Directive:
Pro-active compliance (Product out of EU RoHS legal scope)
Permanent Permissible Load:
150 kg
Toxic Heavy Metal Free:
Yes
Sustainable Offer Status:
Green Premium product
Rohs Exemption Information:
Yes
Circularity Profile:
N/A
Width:
real 500 mm
Material:
polyester
Height:
real 230 mm
Fixing Mode:
by screws M6 - on back inserts
China Rohs Regulation:
Pro-active China RoHS declaration (out of China RoHS legal scope)
Product Or Component Type:
mounting plate
Accessory / Separate Part Category:
mounting accessory
Mercury Free:
Yes
Enclosure Nominal Dimensions:
H: 270 mm W: 540 mm
Reach Free Of Svhc:
Yes
Environmental Disclosure:
ENVPEP110921EN
