Schneider Electric NSYS3D12840P S3D H1200Xw800Xd400+Chassis

(No reviews yet) Write a Review

Write a Review

Schneider Electric NSYS3D12840P S3D H1200Xw800Xd400+Chassis

Rating Required Select Rating 1 star (worst) 2 stars 3 stars (average) 4 stars 5 stars (best)

Name

Email Required

Review Subject Required

Comments Required

SKU:

NSYS3D12840P

UPC:

3.61E+12

MPN:

Condition:

New

Color:

enclosure Gray RAL 7035)

Standards:

IEC 62208

Circularity Profile:

N/A

Nema Degree Of Protection:

NEMA 4X/13

Ip Degree Of Protection:

IP66 IEC 60529

Mercury Free:

Yes

Variant Particularity:

single piece body || gutter-shaped front rail double sheet thickness

Door Opening Side:

reversible 120 °)

Warranty:

18 months

Range:

Spacial

Environmental Disclosure:

ENVPEP100104EN

Product Name:

Spacial S3D

Net Weight:

68 kg

Product Or Component Type:

compact enclosure

Reach Regulation:

Reference contains Substances of Very High Concern above the threshold

Ik Degree Of Protection:

IK10 IEC 62262

Product Certifications:

BV || cUL || DNV || UL || LR || GL

Number Of Doors:

front face 1

Device Application:

multi-purpose

Enclosure Nominal Width:

800 mm

Sustainable Offer Status:

Green Premium product

Door Type:

Solid

Enclosure Nominal Height:

1200 mm

Material:

enclosure steel || mounting plate galvanised steel

Rohs Exemption Information:

Yes

Lock Type:

3 points lock, 3 mm double-bar

Surface Finish:

enclosure epoxy-polyester powder

Accessibility For Operation:

front

Installation Accessory Type:

wall-mounting

Enclosure Nominal Depth:

400 mm

Mounting Plate Description:

plain

Type Of Gland Plate:

standard

Device Composition:

1 body || 2 cable gland plate || 1 mounting plate || 1 door with lock

Removable Parts:

door by hinges || cable gland plate by screws || mounting plate by fixing element

Eu Rohs Directive:

Pro-active compliance (Product out of EU RoHS legal scope)

China Rohs Regulation:

Product out of China RoHS scope. Substance declaration for your information.

Brochure:

View

Datasheet:

View
