Schneider Electric T02BN13B7 NEMA Contactor, TeSys N, nonreversing, Size 0, 18A, 5HP at 460VAC, 3 pole, 3 phase, 24VAC 50/60Hz coil, open
Schneider Electric
$308.00
(No reviews yet)
Write a Review
Write a Review
Schneider Electric
Schneider Electric T02BN13B7 NEMA Contactor, TeSys N, nonreversing, Size 0, 18A, 5HP at 460VAC, 3 pole, 3 phase, 24VAC 50/60Hz coil, open
TeSys N contactors and starters conform to NEMA ICS2 standards. The NEMA size is printed directly on the face of the contactor. This 3 pole NEMA size 0 nonreversing contactor mounts on 35mm DIN rail and has a 18 amperage continuous current rating. This contactor has 1 HP at 115 VAC and 2 HP at 230 VAC single phase ratings. The contactor also has ratings of 3 HP at 200 to 230 VAC and 5 HP at 460 and 575 VAC poly phase. The nonreversing contactor is wired for common control with a 24 VAC 50/60 Hz replaceable coil. Contactor has 1 normally open and 1 normally closed auxiliary contact. This contactor is not in an enclosure. This contactor is 3.34 inches tall, 1.76 inches wide and 3.66 inches deep. It weighs 0.92 lbs. The screw clamp terminals will accept power wires from 18 AWG to 8 AWG and control wires from 18 AWG to 10 AWG. This TeSys N contactor is UL listed and CSA Certified.
- Environmental Disclosure:
- ENVPEP110229EN
- Nema Size:
- 0
- Electrical Connection:
- screw clamp terminals
- Rohs Exemption Information:
- Yes
- Contactor Application:
- non-reversing
- Mercury Free:
- Yes
- Auxiliary Contact Composition:
- 1 NO + 1 NC
- Control Circuit:
- common control circuit
- Range Of Product:
- TeSys N
- [Uc] Control Circuit Voltage:
- 24 V AC
- Line Rated Current:
- 18 A
- China Rohs Regulation:
- Pro-active China RoHS declaration (out of China RoHS legal scope)
- Poles Description:
- 3P
- Pvc Free:
- Yes
- Weight:
- 0.92 lb(US)
- Toxic Heavy Metal Free:
- Yes
- Nema Degree Of Protection:
- not rated (open device)
- Reach Regulation:
- Free of Substances of Very High Concern above the threshold
- Eu Rohs Directive:
- Compliant
- Phase:
- 3 phase
- Depth:
- 3.66 in
- [Ue] Rated Operational Voltage:
- 600 V AC
- Circularity Profile:
- ENVEOLI110229EN
- Reach Free Of Svhc:
- Yes
- Product Certifications:
- UL Listed || CSA
- Product Or Component Type:
- contactor
- Maximum Horse Power Rating:
- 3 hp 200 V AC || 3 hp 230 V AC || 5 hp 460 V AC || 5 hp 575 V AC
- Country of Origin:
- France
- Net Weight:
- 0.92 lb(US)
- Sustainable Offer Status:
- Green Premium product
