| Description | Banana plug; for socket 4 mm | |||||||||||||||||||||||||||||||||||||||||||||||
| Remarks | ||||||||||||||||||||||||||||||||||||||||||||||||
| Item properties | Miscellaneous
| |||||||||||||||||||||||||||||||||||||||||||||||
The WAGO 215 series banana plug is designed for 4mm diameter sockets and is a 1-pole (1P) connector suitable for 2.5mm² wires. It has a rated current of 20A and comes in blue color. The plug features CAGE CLAMP spring connections and supports plug-in mounting with an 8mm width, equivalent to model 215711.
- color:
- Blue
- connection technology:
- CAGE CLAMP
- country of origin sales organisation germany:
- DE
- depth:
- 40 mm / 1.575 inch
- fine stranded conductor:
- 0.08 2.5 mm / 28 14 AWG
- fire load:
- 0.000 MJ
- height:
- 15 mm / 0.591 inch
- main product function:
- Testing accessories
- packaging type:
- Box
- rated current:
- 20 A
- solid conductor:
- 0.08 2.5 mm / 28 14 AWG
- strip length:
- 9 11 mm / 0.35 0.43 inch
- test voltage:
- 42 V
- total number of connection points:
- 1
- total number of potentials:
- 1
- weight:
- 3.876 g
- width:
- 8 mm / 0.315 inch
