WAGO 870-157
Wago
$7.07
4-pin, double-deck carrier terminal block; 4-pin ground conductor terminal block; PE; internal commoning; for DIN-rail 35 x 15 and 35 x 7.5
Electrical Data
- Rated impulse voltage (III / 2): 6 kV
- Rated current: 16 A
Connection Data
- Actuation type: Operating tool
- Total number of potentials: 1
- Number of levels: 2
- Type of wiring: Front-entry wiring
Geometrical Data
- Width: 5 mm / 0.197 inch
- Height from upper-edge of DIN-35 rail: 37.1 mm / 1.461 inch
- Depth: 88.6 mm / 3.488 inch
Mechanical Data
- Design: horizontal
- Type of mounting: DIN-35 rail
- Potential marking: PE
- Marking level: Side marking
Material Data
- Color: green-yellow
- Fire load: 0.185 MJ
- Weight: 11.800 g
Commercial data
- Packaging type: BOX
- Country of origin: DE
- GTIN: 4045454397296
- Customs Tariff No.: 85369010000
The WAGO 870 X-COM series carrier ground/earthing terminal block is a double-deck terminal block with internal commoning and side marking slots, marked with "PE" for protective earth. It is green-yellow in color and designed for 1 grounding/protective-earth connection, accommodating 2 x 2 wires with plug-in pin connections. It supports a rated current of 16A and is mounted on a DIN-35 rail (35 x 15 / 35 x 7.5) with a 5mm width, equivalent to model 870157.
- actuation type:
- Operating tool
- color:
- Green-yellow
- country of origin sales organisation germany:
- DE
- depth from upper edge of din rail:
- 37.1 mm / 1.461 inch
- design:
- Horizontal type
- fire load:
- 0.185 MJ
- flammability class per ul94:
- V0
- height:
- 88.6 mm / 3.488 inch
- marking level:
- Side marking
- mounting type:
- DIN-35 rail
- packaging type:
- Box
- rated current:
- 16 A
- rated surge voltage iii 2:
- 6 kV
- safety information 1:
- 2-conductor female plugs cannot be used.
- weight:
- 11.800 g
- width:
- 5 mm / 0.197 inch
- wiring direction:
- Front-entry wiring
