Datasensing PFM1/AP-3H Sensors
Datasensing
$72.47
The Datasensing PFM1/AP-3H Sensors are designed for precision and durability, featuring an M12 shielded inductive sensor with a NO/PNP connection. Encased in robust AISI 316L stainless steel, these sensors offer exceptional protection with IP67, IP68, and IP69K ratings, making them suitable for harsh environments. The LED status indicator provides clear operational feedback, while the sensor's design ensures complete protection against electrical damages. Available in standard and long-distance models, these sensors have a nominal sensing distance of 4mm and an operating distance of 0 to 3.24mm. They are compatible with standard targets of 12x12mm FE360 and have a correction factor for various materials, including copper, aluminum, brass, and stainless steel. With a thermal drift of less than 10% and repeat accuracy under 5%, these sensors maintain high performance. They feature a switching frequency of 2kHz and operate within a voltage range of 10 to 30Vdc. The sensors are equipped with short-circuit, reverse polarity, and impulsive overvoltage protection, ensuring reliable operation. The M12 plug connection and PPS active head material enhance durability, while the sensors' compact dimensions and lightweight design facilitate easy installation. Approved by CE, cULus, ECOLAB, and DIVERSEY, these sensors meet rigorous standards for electromagnetic compatibility and mechanical protection. Supplied with two M12x1 nuts, they are ready for immediate deployment in demanding industrial applications.
- Nominal sensing distance:
- 4mm
- Operanting distance:
- 0 3,24mm
- Standard target:
- 12x12mm FE360
- Correction Factor:
- copper: 0,30 / aluminium: 0,35 / brass: 0,40 / stainless steel: 0,75
- Thermal drift of Sr:
- < 10%
- Repeat Accuracy:
- < 5% (UB 24V Ta=23°C ±5°C)
- Hysteresis:
- 1 20%
- Description:
- M12 standard flush mount
- Functions:
- Proximity
- Output type:
- PNP
- Output Function:
- NO
- Switching frequency:
- 2kHz
- Operating Voltage:
- 10...30Vdc
- No-Load supply current:
- ? 15mA
- Load current:
- ? 200mA
- Leakage current:
- ? 15?A
- Output voltage drop:
- ? 2V @200mA
- Max ripple content:
- ? 10%
- LED indicators:
- Yellow LED output state
- Time delay before availability:
- ? 50ms
- Short-circuit protection:
- Yes
- Reverse Polarity Protection:
- Yes
- Impulsive Overvoltage Protection:
- Yes
- Protection against inductive loads:
- Yes
- Mounting:
- Shielded
- Weight:
- 30g
- Housing Material:
- AISI316L Stainless Steel
- Connections:
- M12 Plug
- Active Head Material:
- PPS
- Tightening torque:
- 25Nm
- Material:
- AISI316L Stainless Steel
- Diameter/Dimension:
- M12
- Approvals:
- CE cULus ECOLAB DIVERSEY
- EMC compatibility:
- IEC 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-27
- Degree of protection:
- IP68, IP69K
- Supplied Accessories:
- 2 nuts M12x1
- Mechanical Protection:
- IP67
