Schneider Electric HLL26040 Circuit breaker, PowerPacT H, 40A, 2 pole, 600VAC, 50kA, lugs, thermal magnetic, 80%

Schneider Electric HLL26040 Circuit breaker, PowerPacT H, 40A, 2 pole, 600VAC, 50kA, lugs, thermal magnetic, 80%

Schneider Electric
SKU:
HLL26040
$2,364.00
(No reviews yet) Write a Review
Condition:
New
Current Stock:
Description
PowerPacT H-Frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. PowerPacT H-Frame circuit breakers are available with either thermal magnetic or Micrologic electronic trip protection units. This PowerPacT H-Frame circuit breaker provides thermal magnetic circuit protection with a breaking capacity of 50kA at 600VAC. All PowerPacT H-Frame circuit breakers are equipped with dual-break rotating contacts that reduce the amount of peak current during a short circuit fault. All PowerPacT circuit breakers have an integral push-to-trip button in the cover to manually trip the circuit breaker. PowerPacT H circuit breakers are available in 2 and 3-pole unit mount and I-Line constructions. This breaker has lugs on both the line and load sides. This PowerPacT H, 40A, 2 pole, circuit breaker has a breaking capacity of 50kA at 600VAC. This circuit breaker has a continuous current rating of 80%. PowerPacT H circuit breakers comply to UL, CSA, NOM, and IEC standards and are CE marked.
Additional Information
California Proposition 65:
WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information
Protected Poles Description:
2t
Ip Degree Of Protection:
front cover IP40 IEC 60529
[Ui] Rated Insulation Voltage:
750 V IEC 60947-2
Mercury Free:
Yes
Suitability For Isolation:
yes IEC 60947-2
Terminal Identifier:
AL150HD
Pollution Degree:
3 IEC 60947-1
Awg Gauge:
AWG 14...AWG 3/0 aluminium/copper terminal
Quantity Per Set:
1
Product Name:
PowerPact H
Trip Unit Technology:
thermal-magnetic
Tightening Torque:
5-5 N.m 2.5-6 mm² (AWG 14...AWG 10) || 14-14 N.m 10-95 mm² (AWG 8...AWG 3/0)
Sustainable Offer Status:
Green Premium product
Pvc Free:
Yes
[Ics] Rated Service Breaking Capacity:
125 kA 220/240 V AC 50/60 Hz IEC 60947-2 || 100 kA 380/440/415 V AC 50/60 Hz IEC 60947-2 || 50 kA 500/525 V AC 50/60 Hz IEC 60947-2 || 20 kA 250 V DC IEC 60947-2 || 20 kA 500 V DC IEC 60947-2
Network Frequency:
50/60 Hz
Product Or Component Type:
circuit breaker
Standards:
UL || CSA || NEMA || NOM-003-SCFI-2000 || IEC 60947-2
Control Type:
toggle
Line Rated Current:
40-40 A
[Uimp] Rated Impulse Withstand Voltage:
8 kV IEC 60947-2
Circularity Profile:
ENVEOLI2206027EN
China Rohs Regulation:
Product out of China RoHS scope. Substance declaration for your information.
Depth:
86 mm
Number Of Slots:
2 auxiliary switch OF plug-in) || 1 alarm switch SD plug-in) || 1 overcurrent trip switch SDE plug-in) || 1 voltage release MN or MX plug-in)
Device Application:
distribution
Environmental Disclosure:
ENVPEP2206027EN
Poles Description:
2P
Magnetic Tripping Current:
850-850 A
Magnetic Hold Current:
400 A
Weight:
2.2 kg
Local Signaling:
switched off (OFF) 1 trip indicator green)
Eu Rohs Directive:
Compliant with Exemptions
Warranty:
18 months
Net Weight:
2.2 kg
Operating Altitude:
< 6561.68 ft (2000 m) without derating || 5000 m with derating
Circuit Breaker Application:
HACR rated
Utilisation Category:
category A
Country of Origin:
United States
Color:
Black
Product Certifications:
UL || CSA || NOM
Quality Labels:
CE
Mounting Mode:
unit mount lug)
Reach Regulation:
Reference contains Substances of Very High Concern above the threshold
Length:
16 mm
